NVIDIA Mellanox 35m QSFP28 200G HDR Active Optical Cable

Name: NVIDIA Mellanox MFS1S00-H035V 35m QSFP28 200G HDR Active Optical Cable
Brand: NVIDIA / Mellanox
SKU: MFS1S00-H035V
Price: 140 USD
Availability: InStock

Per unit price — new in box

$140

Retail: ~$1,400

90% OFF RETAIL

In stock — ships same day

🛒 Buy Now — $140 Bulk Pricing

🔒 Secure Stripe checkout — we never see or store your card details

💳 Card, Cash App, Klarna, ACH / Bank Transfer — POs & wire accepted for bulk orders

↩️ 30-day returns on unopened factory-sealed units — full policy

✓ New in box — factory sealed, original NVIDIA Mellanox packaging
✓ Genuine OEM — not a compatible clone or third-party substitute
✓ Compatible: QM8700, QM8790, MCX653106A-HDAT, MCX653105A-HDAT
✓ Supports IB HDR 200G and 200GbE simultaneously (VPI)
✓ Same-day shipping — orders before 2 PM CST
✓ Call Sean: 567-485-8018

Technical Specifications

Parameter	Specification
Part Number	MFS1S00-H035V
Cable Length	35m (115ft)
Form Factor	QSFP28 to QSFP28
Data Rate	Up to 200Gb/s (4x 50Gb/s PAM4)
Protocol	InfiniBand HDR 200G, 200GbE (VPI)
Fiber Type	OM3 Multimode Fiber (MMF)
Wavelength	850nm (VCSEL)
Jacket Material	LSZH (Low Smoke Zero Halogen)
Power Consumption	4.35W (typ., each end, with retiming)
Operating Temperature	0°C to 70°C (32°F to 158°F)
Hot Pluggable	Yes
RoHS Compliant	Yes
Condition	New in Box — Factory Sealed

About the MFS1S00-H035V

The NVIDIA Mellanox MFS1S00-H035V is a 35-meter QSFP28 active optical cable for 200Gb/s InfiniBand HDR systems. Note that this SKU uses the QSFP28 form factor rather than QSFP56 — verify your switch and adapter port types before ordering. NVIDIA issued an End-of-Life notice for this variant in March 2022. Our stock of 900 factory-sealed units is among the last available new-in-box supply. At $140 per unit (up to 90% below retail), this represents exceptional value for data centers maintaining existing QSFP28-based HDR infrastructure.

Typical Use Case

The 35m QSFP28 variant is deployed in mid-scale HPC clusters and research computing environments where the spine-to-leaf distance is 30–40 meters and the infrastructure uses QSFP28 port switches such as earlier-generation Mellanox SB7800 series.

New In Box vs. Compatible — Why It Matters

NVIDIA Quantum HDR switches and ConnectX-6/7 adapters perform firmware-level cable authentication at link initialization. Genuine OEM cables like the MFS1S00-H035V pass all NVIDIA firmware checks without modification, ensuring full 200G performance and BER compliance. Third-party compatible cables can trigger firmware warnings and cause intermittent link drops under sustained load.

🔍

Why Are Brand-New Cables Available at 90% Below Retail?

These 12,006 cables were purchased new by a large enterprise customer for a planned HDR InfiniBand fabric deployment. The project was cancelled before installation — the cables were never racked, never powered, never touched. They remain in their original NVIDIA Mellanox factory packaging, exactly as shipped from the manufacturer.

The result: genuine, factory-sealed NVIDIA Mellanox hardware available at project-liquidation pricing. This is a one-time inventory event. When these units are gone, new-in-box HDR cables at this price will not exist again.

Order MFS1S00-H035V

In stock at $140/unit (90% below retail). For bulk orders of 10+ units, fill out the form or call 567-485-8018.
